Heat pump ALPHA INNOTEC L12 Split -HT 12 with integrated 180 l tank for hot water, power 9-12 kW
SKU:
100627HT1201
8,220.99 €
/pcs.
vnt. 9,134.29 €
vnt. 9,134.29 €
6 794,21 € (Tax excluded)
-
Safe shopping -
Fast delivery -
Money back guarantee
| LPExpress | 2-3 business days |  |
| Collect in store | Pick up from our pick-up point |  |
| Courier delivery | 2-3 business days |  |
Heat Pump ALPHA INNOTEC L12 Split -HT 12 with integrated 180 l hot water tank, power 9-12 kW
Alpha innotec ECO LINE heat pumps are an economical way to install future-oriented heating systems. Due to their compact size, they are easy to integrate into homes where every square meter counts.
A wide range of accessories and the reversible design of the units allow for heating, cooling, and hot water preparation in one system, making them ideal for both renovated and newly constructed buildings.
Integrated cooling
Alongside heating and hot water preparation with the ECO LINE L Split, you can also cool economically: the integrated reverse function reverses the heat pump process and utilizes your heating system (floor or ceiling heating) or fan convectors for indoor cooling. This way, the heat pump ensures a comfortable temperature in your home all year round.
Flexible installation options
Due to the separation of the outdoor and indoor units, valuable space can be saved indoors. The HT Split indoor unit, with almost all heating system components and a volumetric water heater integrated, occupies only 0.4 m2, fitting even in a small niche. With the small diameter of the refrigerant pipes, the outdoor unit can be installed in the most suitable location outdoors, even up to 30 m away.
Access from anywhere in the world - convenient online control
Using myUpway, you can control your heat pump system from anywhere in the world using a personal computer, tablet, or smartphone.
Inverter technology
Thanks to inverter technology, ECO LINE L Split heat pumps adjust their power to the current demand. As a result, they operate at partial capacity for most of the year, rarely turning off. This increases efficiency, saves energy, and reduces electricity costs.
Advantages of Alpha Innotec ECO LINE heat pumps:
- Inverter technology.
- Automatic power adjustment to demand.
- Heating, cooling, and hot water preparation with one system.
- Heated condensate tray.
- User-friendly controller with a color menu in Lithuanian.
- Takes up little space.
- Flexible installation options.
- Equipped with emergency condensate removal from the indoor unit.
- In case of pump failure, heating can be manually activated there.
- Remote internet control option* - *Requires internet connection (additional charges may apply).
- Professional technical service in Lithuania.
Quick installation components factory-installed in the units:
- Controller with a color display and menu in Lithuanian.
- Volumetric 180 l water heater.
- Maintenance-free sacrificial anode.
- Assisting 9 kW electric heater.
- Efficient variable speed circulation pump.
- Expansion vessel, 10 l.
- Heat meter.
- Safety group for the heating system.
- Outdoor and indoor temperature sensors.
Heating water temperature from 20℃ to 58℃, up to +65℃ with auxiliary electric heater.
Recommended working outdoor temperature limits: -20℃ to +43℃
Technical specifications:
- Outdoor unit - indoor unit: L12 Split -HT 12
- For buildings with a total heat demand: 9-12 kW
- Heated area: 100-230 m2
- Heating power at: A-7/W35 - 9.0 kW, A-7/W35 - 5.21 kW
- COP at: A27/W35 - 4.78 kW (1)
- Cooling power at: A27/W18 - 11.7 kW
- EER A27/W18 - 3.52 (1)
- Sound power level EN12102, A7/W35 - 58 dB (A)
- Energy efficiency class* A++
- Indoor unit height: 1735 mm
- Indoor unit depth: 610.5 mm
- Indoor unit width: 600.5 mm
- Water preparation: integrated boiler 180 l
- With integrated passive cooling
- Installation type: Split
- Efficient operation: down to -25 degrees
- Electric current: Three-phase
- Copper pipes with insulation: 3/8 and 5/8 diameter
-
Wifi control: additional option (RBE+, remote control with touch screen, integrated indoor
temperature and relative humidity sensor, product code: 15214801) - Outdoor unit dimensions: 970 x 370 x 845 mm
- Weight: indoor unit 165 kg, outdoor unit 74 kg
(1) At partial power | * Heating device with controller (A+++ to G)
For professional heat pump installation, you will need additional items.
Main installation accessories for the outdoor unit:
- SP 850, ground console for L Split heat pumps, galvanized and painted RAL 7021), with anti-vibration pads, product code: HP206005
- AV 201, set of anti-vibration pads (4 pcs.) for heat pumps up to 120 kg, product code: 15213801
- KWS 3/1 Split, condensate hose with electric heating, length 1 m, product code: 15213801
- Insulated copper pipes connecting the outdoor unit to the indoor unit: 3/8 and 5/8 diameter
Main installation accessories for the indoor unit:
- Wall-mounted buffer tank for heating and cooling WPS 61, LWD & HMD2, 60 l, product code: 15085501
- UVD 3/4", excess flow valve 3/4", product code: 15071001
- Ball valve with integrated dirt trap, type 380-20, mesh 0.6 mm, 3/4" connection, Kvs 7, 14, PN16, product code: 438002000
- Expansion vessel for water 18 l;
- Expansion vessel connection valve 3/4"
- Circulation pump for hot water, product code: 4132760
Warranty: 5 years
Manufacturer: ALPHA INNOTEC (Germany)
