Aluminum radiator FONDITAL Exclusifo 500/100 - 23 sections
SKU:
F500-100-23S
460.01 €
/pcs.
vnt. 837.01 €
vnt. 837.01 €
380,17 € (Tax excluded)
-
Safe shopping -
Fast delivery -
Money back guarantee
| LPExpress | 2-3 business days |  |
| Collect in store | Pick up from our pick-up point |  |
| Courier delivery | 2-3 business days |  |
Multilayer pipe with 6 mm insulation (red) TECEflex PE-Xc/AL/PE-RT 25 x 2.8 mm (50 m)
The multilayer TECEflex pipe is made from a base PE-Xc pipe, which is covered with a laser-welded aluminum shell (the latter is further covered with a white protective PE-RT layer). The aluminum shell serves as a diffusion oxygen barrier while also reducing the linear expansion of the pipe, which is characteristic of all polyethylene pipes. The universal PE-Xc/AL/PE pipe has all the best properties of both metal and polyethylene pipes - low linear expansion, flexibility, resistance to high temperature and pressure loads, and corrosion. The white color allows this pipe to be installed in open, visible places. The patented TECEflex pipe connection method uses clamping rings without any rubber sealing gaskets, preserving minimal cross-section narrowing at the connection point. The same fittings are used for TECEflex multilayer pipes as for TECEflex heating and water supply pipes.
TECEflex - universal piping system DN 14-63 mm:
The universal piping system "TECEflex" is designed for the installation of water supply, heating, and compressed air systems
TECEflex - time-tested connection
TECEflex - the piping connection technology is an axial pressing system. Millions of connections made leave no doubt about the system's reliability and durability. Multilayer (PE-Xc/AL/PE) and PE-Xc pipes are connected using simple pipe expansion and ring clamping tools. And this has not changed for 25 years.
TECEflex - incorrect connection control. Impossible to overlook.
If the connection is made incorrectly, a leak will appear immediately after the system is filled. In other systems, due to poorly made connections, a leak may not appear immediately:
1. Clearly visible incomplete connection. The ring is not fully tightened.
2. A leak appears immediately after filling the system.
3. Correctly made connection. No leak, the ring is fully tightened on the fitting and THIS IS CLEARLY VISIBLE.
Brass - for future engineering systems...
Since December 1, 2013, only brass fittings can be used in water supply systems installed in Germany and the Netherlands. It is only a matter of time before this will also be the case with us. The new material fully meets the tightened requirements for engineering systems. It complies with the currently valid standards:
- Water supply systems DIN 1988 / DIN EN 806
- Gas supply systems DVGW TRGI 2008
- Heating systems
- Compressed air systems
- Purpose: in water supply, heating, as well as in underfloor heating installations, in the installation of main risers, and floor channels.
- Packaging (roll): 16 mm - 75 m, 20 mm - 75 m, 25 mm - 50 m, 32 mm - 25 m, smaller quantities can also be purchased
- For bending pipes, it is recommended to have pipe bending springs or other bending tools
PPSU - plastic fittings for heating and water supply
As an alternative to brass fittings, cheaper fittings made from PPSU can also be used. PPSU is a plastic that is particularly resistant to mechanical impact and shocks. The DVGW recommended "TECEflex" PPSU fittings are resistant to corrosion, shocks, pressure, temperature effects, and are also durable. Impeccable hygiene properties guarantee excellent use of these fittings. PPSU fittings are applied in heating and water supply systems.
Standard brass
An inexpensive metal alternative to brass - fittings made from standard brass. Fittings can be used without restrictions in heating and compressed air systems, with certain restrictions in drinking water systems. They can also be used for gas installations.
When purchasing multilayer pipes and fittings from us, the rental of plumbing tools is free!
NOTE: additionally, a clamping ring must be purchased according to the connection diameter: 16, 20, 25, 32, 40, 50, 63 mm
More information is available in the downloadable files.
Manufacturer: TECE (Germany)
Product images are for illustrative purposes only and are examples. The video links in the product description are for informational purposes only, so the information provided may differ from the actual product. The colors, inscriptions, parameters, dimensions, sizes, functions, and/or any other properties of the original products may appear differently than in reality due to their visual characteristics, so please refer to the product specifications listed in the product descriptions. If you have any questions, please contact us via the email or phone numbers provided in the contact section.
F500-100-23S
