New generation air-water heat pump 5 kW PANASONIC, with 200 l capacity, single-phase.
SKU:
KIT-WC05J3E5 (WH-SDC0305J3E5/WH-UD05JE5)
4,860.00 €
/pcs.
vnt. 7,484.00 €
vnt. 7,484.00 €
4 016,53 € (Tax excluded)
-
Safe shopping -
Fast delivery -
Money back guarantee
| LPExpress | 2-3 business days |  |
| Collect in store | Pick up from our pick-up point |  |
| Courier delivery | 2-3 business days |  |
Plate heat exchanger with enthalpy heat exchanger BROFER 370 m³/h RDCD50SHE+4BRF
The Brofer plate heat exchanger maintains efficiency in winter - up to 90%. The heat exchanger features an automatic by-pass function. This function prevents warm air from entering the room when it is not needed, for example, in summer. It is equipped with an electronic commutation fan (EC fan), which allows the heat exchanger to operate more quietly. Most models of Brofer heat exchangers are made from excellent sound-absorbing multilayer panels. These heat exchangers, known for their high heat recovery efficiency, can be installed horizontally or vertically. The plate, counterflow type heat exchanger is made of plastic, with a built-in condensate collection system. The devices come with a standard synthetic fiber filter with G4 efficiency, and higher-class filters can achieve F7 efficiency for clean air. The heat exchanger fan is equipped with EC motors (brushless).
Improved filtration quality
Healthy air is another important factor for well-being. Therefore, this device is equipped with next-generation filters that reduce dust levels in the heat exchanger and throughout the air distribution system. Various types of filters are available: G4, F7, carbon. For better air permeability and filtration, the filters have a pleated design. Filter maintenance is simple due to the automatic notification system. The device alerts when filters need to be changed.
Top fan technology
Quiet, energy-saving fan operation. The flow grid, scroll housing, and impeller ensure the best possible air flow. This guarantees not only very quiet operation but also exceptionally low energy consumption.
Moisture recovery
The enthalpy heat exchanger is similar to a standard plate heat exchanger, but its plates are made of a patented polymer membrane instead of plastic. The membrane structure allows only water vapor molecules to move from one side of the membrane to the other, which are significantly smaller than microbes or odor molecules. A comparison can be made to a high-quality moisture-permeable ski jacket, which allows water vapor to escape while preventing rain from entering.
The enthalpy heat exchanger combines the positive properties of rotary and plate heat exchangers: frost resistance, high efficiency, moisture recovery, and hygiene.
These moisture-recovering heat exchangers are highly efficient and at the same time significantly more frost-resistant than conventional plate heat exchangers (due to moisture recovery, no condensate forms in the heat exchanger, so there is nothing to freeze).
Thanks to the enthalpy function, much more moisture is retained during the winter months, making the indoor climate significantly more comfortable.
Advantages:
- Convenient ventilation up to 370 m³/h
- Heat exchanger type - counterflow with moisture recovery function (Enthalpy)
- Efficiency (at maximum air flow) up to 90.5%
- Fans with constant volume flow control and balancing
- No condensate connection required
- Quick, safe installation and maintenance
- Time or sensor-controlled automatic functions
- Improved filtration quality
- Operates very quietly. The sound level is 57 dB (A)
- Modulated bypass adapts to outdoor temperature to ensure ideal comfort regardless of outdoor temperature, minimizing energy loss
- High efficiency of the counterflow heat exchanger
- Standard equipment includes: wireless remote control, external electric heating element
- Innovative air volume balancing for maximum heat recovery
- Adaptive pre-heater for advanced control of incoming outdoor air temperature for optimal energy consumption
- Condensate heat exchanger made of aluminum foil. This heat exchanger effectively saves heat, returning some of the air moisture to the room while expelling the rest outside.
Technical specifications:
- Suitable for up to 180 m² room
- Air volume (at 100 Pa) max. 375 m³/h
- Heat exchanger type - counterflow with moisture recovery function (Enthalpy)
- Max electrical power – 169 W (230 V)
- Operating range (external environment) -20 - +50 C
- Efficiency class – A++
- Filters G4, Wireless control
- Automatic BY-PASS
- EC fans
- Thermal efficiency according to PHI* - 91%
- Specific fan power (SPI) according to PHI* - 0.21 W/m³/h
- Duct connections - Ø 160 mm
- Dimensions (H x W x D) - 710 x 610 x 797 mm
- Sound level, dB(A) - 57
- Heat exchanger type - condensate
- Heat exchanger type - plate
- Standard equipment includes: wireless remote control, electric heating element
- Weight: 41 kg
* PHI=Passive House Institute
Warranty: 2 years
Manufacturer: BROFER (Italy)
