Water in the shield (standing) heat pump SINCLAIR 150 l, SWPN150
SKU:
SWPN150
779.00 €
/pcs.
vnt.
vnt.
643,80 € (Tax excluded)
-
Safe shopping -
Fast delivery -
Money back guarantee
| LPExpress | 2-3 business days |  |
| Collect in store | Pick up from our pick-up point |  |
| Courier delivery | 2-3 business days |  |
Water heater (floor standing) for heat pump SINCLAIR 150 l, SWPN150
SWP N 150 water heater with one large surface heat exchanger Sunsystem
Volume water heater SWP N 150 with one large surface heat exchanger. Designed for use in heat pump systems or when a large amount of hot water is required.
Hot drinking water is aggressive when interacting with black steel. To protect the tank from corrosion, it must be insulated from hot drinking water. All Sunsystem water heaters are internally coated with titanium enamel. It is fired and becomes smooth and glossy. As a result, hot water remains clean and the tank is protected from corrosion.
The quality of the water heater's insulation is a crucial factor in ensuring heat retention and energy efficiency. All Sunsystem floor standing water heaters up to 500 liters in volume are externally protected using 50 mm thick PPU rigid polyurethane foam insulation from the global leader BASF. All larger volume water heaters are equipped with removable 100 mm thick PPU flexible polyurethane foam insulation.
All Sunsystem black steel enamelled water heaters are also equipped with a second layer of corrosion protection - a soluble magnesium anode. The anode protection works in two ways:
Reduces the electrical potential in the tank
Creates a protective film on the metal surface, thus protecting the tank from contact with water
An inspection/cleaning flange is installed at the lower part of the water heater. In certain models, a place for the electric heating element is provided in the blind flange of the enamelled steel.
Technical specifications:
- Water heater volume – 150 liters
- Water heater height / conversion height - 1070 / 1210 mm
- Water heater diameter – 560 mm
- Insulation thickness – 50 mm
- Max working pressure / temperature of the tank - 10 bar / 95 oC
- Max working pressure / temperature of the heat exchanger - 16 bar / 110 oC
- Tank test pressure – 15 bar
- Lower heat exchanger area / volume – 1.4 m2 / 8.6 l
- Lower heat exchanger power – 40.4 kW
- Lower heat exchanger pressure losses – 120 mbar
- Heat exchangers test pressure – 25 bar
- Installation: floor standing
- Thermometer – included
- Soluble magnesium anode – included
- Place for electric heating element – included
- Weight – 70 kg
Place for electric heating element 6/4" (in the flange).
Included are a thermometer, 3 legs, and a safety valve.
Warranty: 5 years for the tank, 2 years for the electric parts and connections,
Brand: SINCLAIR (Italy), manufacturer: SANSYSTEM (Italy)
