Water heater (installed) heat pump SINCLAIR 300 l, SWPNL300
SKU:
SWPNL300
1,075.00 €
/pcs.
vnt.
vnt.
888,43 € (Tax excluded)
-
Safe shopping -
Fast delivery -
Money back guarantee
| LPExpress | 2-3 business days |  |
| Collect in store | Pick up from our pick-up point |  |
| Courier delivery | 2-3 business days |  |
Water heater (floor-mounted) for heat pump SINCLAIR 300 l, SWPNL300
Storage water heater SWP NL 300 with one large surface heat exchanger
Storage water heater SWP NL 300 with one large surface heat exchanger. Designed for use in heat pump systems or when a large amount of hot water is required.
Hot drinking water is aggressive when interacting with black steel. To protect the tank from corrosion, it must be insulated from hot drinking water. All Sunsystem water heaters are internally coated with titanium enamel. It is fired and becomes smooth and glossy. As a result, hot water remains clean and the tank is protected from corrosion.
The quality of the water heater's insulation is a crucial factor in ensuring heat retention and energy efficiency. All Sunsystem floor-mounted water heaters up to 500 liters in volume are externally protected using 50 mm thick PPU rigid polyurethane foam insulation from the global leader BASF. All larger volume water heaters are equipped with removable 100 mm thick PPU flexible polyurethane foam insulation.
All Sunsystem black steel enamel water heaters are also equipped with a second layer of corrosion protection - a soluble magnesium anode. The anode protection works in two ways:
- Reduces the electrical potential in the tank
- Creates a protective film on the metal surface, thus protecting the tank from contact with water
An inspection/cleaning flange is installed at the lower part of the water heater. In certain models, the location for the electric heating element is provided in the blind of the enamel-coated steel flange.
Technical specifications:
- Water heater volume – 300 liters
- Water heater height / conversion height - 1695 / 1801 mm
- Water heater diameter – 610 mm
- Insulation thickness – 50 mm
- Max working pressure / temperature of the tank - 10 bar / 95 oC
- Max working pressure / temperature of the heat exchanger - 16 bar / 110 oC
- Tank test pressure – 15 bar
- Lower heat exchanger area / volume – 3.3 m2 / 20.4 l
- Lower heat exchanger power – 90 kW
- Lower heat exchanger pressure losses – 230 mbar
- Heat exchangers test pressure – 25 bar
- Thermometer – included
- Soluble magnesium anode – included
- Location for electric heating element – included
- Weight – 131 kg
Location for electric heating element 6/4" (in the flange).
Included are a thermometer, 3 legs, and a safety valve.
Warranty: 5 years for the tank, 2 years for the electric part and connections,
Brand: SINCLAIR (Italy), manufacturer: SANSYSTEM (Italy)
Product images are for illustrative purposes only and are sample representations. Video links in the product description are for informational purposes only, and the information provided may differ from the actual product. The colors, inscriptions, parameters, dimensions, sizes, functions, and/or any other features of the original products may appear differently than in reality due to their visual characteristics, so please refer to the product specifications listed in the product descriptions. If you have any questions, please contact us via email or phone listed in the contact section.
